Hercules Mild Steel Breathing Apparatus Cabinet

This is a wall mounted fire extinguisher cabinet, made of 1.2mm Electro Galvanised plate with a plain viewing glass. FUNCTIONS: It is weatherproof, Outdoor UV Resistant coated with polyester powder, has a Big Viewing Glass for Easy Identification of Fire Extinguisher and is available in different colour for different environment. Ordering Matrix:

MODEL	LOCK TYPE	SIZE	WEIGHT (APPROX.)	USAGE
C-S1MW	Lock & Key	220mm(W) x 175mm(D) x 575mm(H)	6kg	2-3kg
C-S2MW	Thumb Latch Lock	220mm(W) x 175mm(D) x 575mm(H)	6kg	2-3kg
C-M1MW	Lock & Key	260mm(W) x 200mm(D) x 610mm(H)	7kg	4kg
C-M2MW	Thumb Latch Lock	260mm(W) x 200mm(D) x 610mm(H)	7kg	4kg
C-L51MW	Lock & Key	350mm(W) x 220mm(D) x 820mm(H)	10kg	5kg
C-L52MW	Thumb Latch Lock	350mm(W) x 220mm(D) x 820mm(H)	10kg	5kg
C-L1MW	Lock & Key	300mm(W) x 220mm(D) x 770mm(H)	12kg	6-9kg
C-L2MW	Thumb Latch Lock	300mm(W) x 220mm(D) x 770mm(H)	12kg	6-9kg

  For enquiry please contact us:

Rather than the conventional breakable glass, the clear panel is composed of durable plastic. Glass has long been seen as a severe safety hazard for youngsters. There is no risk of youngsters getting cut when using plastic, and the fire extinguisher remains visible.

Brand	Inner Height x Inner Width x Inner Depth (mm)	Outer Height x Outer Width x Outer Depth (mm)
Hercules	410 x 150 x 160	460 x 230 x 160

What types of fire extinguisher can it fit? Suitable with Hercules 1 2 3 KG Dry Powder Fire Extinguishers as well as fire extinguishers up to 410mm in height. Where/what places is this cabinet needed? This cabinet is ideal for schools, child care facilities, and other locations where a large number of people will be present.   For enquiry please contact us:

This is a wall mounted fire extinguisher cabinet, made of 1.2mm Electro Galvanised plate with a plain viewing glass. FUNCTIONS: It is Outdoor UV Resistant coated with polyester powder, has a Big Viewing Glass for Easy Identification of Fire Extinguisher and is available in different colour for different environment. Ordering Matrix:

MODEL	LOCK TYPE	SIZE	WEIGHT (APPROX.)	USAGE
C-S1M	Lock & Key	220mm(W) x 175mm(D) x 510mm(H)	4.5kg	2-3kg
C-S2M	Thumb Latch Lock	220mm(W) x 175mm(D) x 510mm(H)	4.5kg	2-3kg
C-M1M	Lock & Key	260mm(W) x 200mm(D) x 540mm(H)	5.5kg	4kg
C-M2M	Thumb Latch Lock	260mm(W) x 200mm(D) x 540mm(H)	5.5kg	4kg
C-L51M	Lock & Key	350mm(W) x 220mm(D) x 750mm(H)	10kg	5kg
C-L52M	Thumb Latch Lock	350mm(W) x 220mm(D) x 750mm(H)	10kg	5kg
C-L1M	Lock & Key	300mm(W) x 220mm(D) x 700mm(H)	8kg	6-9kg
C-L2M	Thumb Latch Lock	300mm(W) x 220mm(D) x 700mm(H)	8kg	6-9kg

  For enquiry please contact us:

This Stainless Steel Hose Reel Cabinet is made of 1.5mm Thickness, Stainless Steel 316 and is dent resistant, it will also fit all standard sized hose reels.

Type	Height	Width	Depth
HR CA	790mm	790mm	360mm

  For enquiry please contact us:
